AXIS POWER SUPPLY DIN PS56 240W

AXIS POWER SUPPLY DIN PS56 240W

Compact industrial power supply

  • Output: 56 V DC
  • Operating temperature: -25 to 70 °C (-13 to 158 °F)

$289.00 USD

The UL certified power supply provides 56 V DC and is ideal for installation in AXIS Surveillance cabinets. With a wide operating temperature, from -25 °C to 70 °C (-13 °F to 158 °F), it provides power to DC powered PoE switches, even in harsh environments.

Power supply DIN PS56 240 W is a reliable power supply with high power. It has a compact design and high efficiency, making it cost-effective and easy to maintain.

Product Number: 01726-001

Input:

AC current consumption 1,5 A @ 230 V AC / 3 A @ 115 V AC
AC input voltage range 85-277 V AC (Derating @ 100 V AC)
DC current consumption 1,5 A @ 370 V DC / 3 A @ 120 V DC
DC input voltage range 80-370 V DC
Input frequency 45-65 Hz
Rated input voltage 100-240 V AC (wide-range input)



Output:

Output power 240 W
Output voltage 56 V DC
Output voltage 30-56 V (adjustable via potentiometer)
Category:
Weight 2.71 lbs
Dimensions 7.60 × 4.09 × 9.84 in
Product Number

01726-001
